Adjustable Heavy Duty Steel Prop For Construction

Product Description



Prop system
Prop is a main part in Formwork project, A complete set of steel prop consists of an inner tube, an outer tube, a prop nut, a Jack plate and a Base plate. it can be adjusted to any length inside its range. Shoring props are known by several names including: scaffolding prop, formwork prop, industrial prop, building prop, shore prop, acro prop, acro jack, acrow prop and post shores. They are height adjustable by a wide diameter screw thread, which is on the outside of the tube. The use of a screw thread means that the props are able to be tightened when already in place, which allows the user to adjust the load that each one bears.
The sizes are available from 1500mm to 5000mm with working bearing load limits from 20kN to 30kN.
Feature
* Convenient erection with the assistant of tripod
* 20kN(D class) & 30kN(E class) at different open lengths for your selection
* Anti-dislocation of inner tubes flying out of outer tube
* 100mm safe zone design on the top of inner tube avoiding any injury on the hands of users
* Hot dip galvanization treatment prevent the prop from corrosion, other treatment like painting and electro galvanization are also available
* According to EN 1065 standard
Application
For shoring purpose, in various kind of slab projects.

Product Parameters

SPECIFICATIONS FOR ADJUSTABLE STEEL PROP
Description	Building Material Heavy Duty Scaffolding/scaffold formwork clamp system Adjustable Steel Prop
Tube size	48/60mm, 40/48mm, 48/56mm
Tube Thickness	1.6-4.0mm
Adjustable Length	2400-3900mm, 2000-3500mm, 3000-5500mm or as per your drawing
Surface treatment	Hot dipped Galvanized, Pre galvanized, Painted, Powder coater
Type	Heavy Duty, Light Duty
MOQ	One container
Delivery time	within 20 days
Application	scaffolding and formwork







Detailed Photos

Product Processing

Product Tests
Product Application

Packaging & Shipping



FAQ

Q1: Where is your warehouse located? How can I visit your company?

A1: Our warehouse is located inTianjin, about 10min drive from our office.All our clients, from home or abroad, are warmly welcome to take a visit here!

Q2: How does your company do regarding quality control?

A2: Quality is very important and always be put at the first place. SLM team members always pay great attention to quality controlling from the very beginning to the end.

Q3: Can I get some samples?

A3: Yes, sure, we are honored to offer you samples.

Q4: What is your method of Transportation?

A4: We deliver by shipping, container, break bulk or as your requirements.

Q5: What's your Payment method supported?

A5: We accept T/T, L/C at sight etc.
